Coaxial holes that are aligned through different features can be controlled with positional tolerancing using a feature relating zone for each hole and a pattern locating zone for the holes as a group.

Question

Quizplus · Accepted Answer

This statement is true. Positional tolerancing using a feature relating zone for each hole and a pattern locating zone for the holes as a group can effectively control the alignment of coaxial holes through different features.
